MIG Wire Drawing And Online Copper electroplating line
Main specification 1. Production process 1.1 First step:Drawing 5.0/5.5mm to 0.8-2.0mm and copper plating to manufacture 0.8-2.0mm MIG wire 1.2 Second step:Layer spooling MIG wire 0.8-2.0mm on 270/300 spools 1.3 Third step:Barrels Winding wire 250-350kg/barrel 2. Equipment capacity [1]. According to 0.8mm-30%, 1.2mm-50%, other 20% considered. [2]. The annual working hours are 6600 hours, 330 days per year, and the production capacity is considered 20 hours per day. [3]. Capacity of SDMP500/7+400/7+2 drawing and copper plating line is 2400 tons / year of 1.2mm 3:Video sites 1. SDMP500/5+400/7+2 drawing with copper plating https://youtube.com/shorts/qVyzQGVL6ng?feature=share 2. NL-5DA Automatic layer spooling https://youtu.be/E99GSbkv27A 3. BWM500 Barrels winding machine https://youtube.com/shorts/Ss91xucswHo?feature=share
