Wire and Cable High Voltage Withstand, Insulation Resistance, Conductor DC Resistance Tester

Product description: One integrated auto tester which is a comprehensive set of high voltage withstand tester, insulation resistance tester, low DC resistance tester, equipped with a set of computer and a printer to record and print test results to ensure product traceability. And compared to traditional split machine, integration, visibility, intelligence has been greatly improved. Under the security situation, after the tester holds the sample to be tested properly, in the whole testing process, no need human intervention, the machine automatically conducts grouping test, thus improving test rate and also stopping the tester contact with high voltage, increase the safety factor of testers. Enable to edit, save and recall test methods of different products. In the production process of testing, the same product can be called directly, no need to re-edit the test method. According to the customized test method, the testing machine is of one-button start testing. Just click on the start of the machine to automatically complete the test, by comparing the test results and the test requirements, enable to automatically determine whether the sample is qualified, and generate the corresponding test report. Adopted a high-performance microprocessor-controlled insulation resistance tester, voltage continuously adjustable, enable to test the resistance of 500Ω ~ 50TΩ, the maximum displayed number is 9999, the test rate is up to 20 times / s Standards: GB / T3048.5-2007; GB / T3048.4-2007; Technical Parameters: High voltage withstand: • Test voltage: AC 5KV • Rated capacity: 5KVA • Voltage waveform: sine wave • Voltage error: ± 3% • Test time: 0 ~ 9999S, settable • Control mode: electric boost • Voltage increasing mode: auto • Overcurrent protection Insulation resistance: • Output voltage: DC10V ~ 1000V continuously adjustable • Basic voltage accuracy: ≥10V: ± (0.1%±5 readings), <10V: ± (0.3%±5 readings) • Resistance measurement basic error: Measuring range Basic error 0-107Ω ±( 1 %Rx+ 2 digitals) ＞107—1010Ω ±( 3 % Rx+ 2 digitals) ＞1010—1012Ω ±( 5 % Rx+ 2 digitals) ＞1012 ±( 10 % Rx+3 digitals) • Wherein Rx: meter reading value (shown resistance value) Insulation resistance: • Operation environment a. reference conditions: temperature of 20 ℃ ± 0.5 ℃, relative humidity of 40% -60% b. nominal conditions: temperature of 10 ℃ -30 ℃, relative humidity of 25% -75% Main parameters of each range: Measuring range Test current Resolution Measuring range Basic error 200μΩ 10A 0.01μΩ 0-199.9999μΩ ±0.5%Rx 2mΩ 10A 0.1μΩ 0-1.9999mΩ 20mΩ 1A 1μΩ 0-19.9999mΩ ±0.3%Rx 200mΩ 0.5A 10μΩ 0-199.9999mΩ 2Ω 100mA 100μΩ 0-1.9999Ω ±0.05%Rx 20Ω 100mA 1mΩ 0-19.9999Ω 200Ω 10mA 10mΩ 0-199.9999Ω 2kΩ 1mA 100mΩ 0-1.9999kΩ • Temperature accuracy: 0.5 ℃ ± 0.5 ℃ Specifications: • Overall dimensions: Approx. 1350 (L) × 600 (W) × 1700 (H) mm • Power supply: AC380V 50 / 60Hz
