Two Roll Mill Machine

Product description: Two Roll Mill Machine is used for plasticization and dispersion of masterbatch, PVC, plastic, pigment, adopted the electric heating specialized mould, double-roller mirror chrome plated, temperature uniformity, adjustable roller gap space, a safety protection device, good dispersion, light and easy to use Typical applications: • Mixture, color test, tabletting of raw materials • Color matching test • Hardness test • Testing stabilizer • Physical test • Chemical test • All kinds of special ingredients • Small scale production Specifications: Temperature Room temperature～200℃ Temperature controller LED digital display, button setting and input, digital display output Temperature precision ±3.5℃ Heating method Tubular electric heating element Heating up time It takes about 30min from room temperature to 200℃ Ratio of revolution 1: 1.27 Number of revolution Constant rate/rate governing(optional) Roller spacing 0.1～10mm Roller size(ø×L) ø120×L320mm/ø150×L320mm(optional) Roller surface HRC 60 mirror-like chrome plating Power 5KW Safety protection Pull rod stop, knee top reverse and other security devices Dimensions (W×D×H) About 1200×600×1380mm Power supply 3∮, AC380V,22A, three-phase five-wire Weight About 375kg
