Soldering Tester

Product description: Soldering tester adopted with advanced machinery, record the displacement and time traveled in the whole process of test by electronic PCI capture card, to research if the spacer layer between un-tinning conductors and insulators is valid or not Standard: • GB / T 5013.2-2008 • GB / T60245-2 Technical parameters: • Cross-sectional diameter range of holding specimen: φ1-φ9 • Effective stroke: about 110mm • Test rate range: 25mm / s • Drive connecting plate: high carbon steel forged, good mechanical performance, without deformation • Drive screw: §8 high precision gapless ball screw, non-deformation after being used for a long time Grips: Self-tightening drill chuck • Guide rod bearings: JBDQ inlaid graphite bearing • Guide rod: it’s made of two ∮12 Korean Taijing guide rods, whose surface is being processed by high temperature and hard chrome electroplating, HRC is over 60 • Tin furnace temperature: 270 ℃ Specifications: • Overall dimensions: 500mm×505mm×970mm • Power supply: 220V 50 / 60HZ
