Low Temperature Winding Test Device
Product description: Low temperature winding test device is used to examine the property of round cables and round insulated wire core under the low temperature conditions Standard: • GB/T 2951.14-2008 Technical parameters: • Low temperature winding specimen diameter: Ф2.5～Ф12.5mm • Winding rod diameter: Ф4, Ф5, Ф6, Ф7, Ф8, Ф10, Ф12, Ф14, Ф16, Ф20, Ф24, Ф28, Ф32, Ф36, Ф40, Ф45, Ф50, one of each; 17 in total • Through wire sheath: Ф1.2, Ф2.4, Ф3, Ф3.8, Ф4.7, Ф5.9, Ф7.4, Ф9.2, Ф11.5, Ф14.5, two of each • Specimen winding coil number: 2～10 coils • All the devices of this series are made of stainless steel • This tester is used in conjunction with the low temperature chamber Specifications: • Overall dimensions: 310mm×450mm×320mm
