IEC60245.8:1998 • GB/T 5013.8-2008 • GB/T 5013.2-2008 Rubber Insulated Cables Flexibility Tester

Product description: Rubber insulated cables flexibility tester is suitable for the two-core and three-core sheathed cable that conductor cross-sectional area is 1.5mm2 or less, in line with standard IEC60245.8:1998 Standard: • IEC60245.8:1998 • GB/T 5013.8-2008 • GB/T 5013.2-2008 Technical parameters: • Specimen voltage: 220/450V (adjustable) • Conductor cross-sectional area: 0.75mm2～1.5mm2 • Test current: 6 -20A • Specimen length: 1000mm • Testing times: 3000 times (back and forth) • Loading: 10, 20, 25, 30, 50, 70, 100N • Upper grip displacement speed: 9 times (back and forth)/Min • Total length of upper and lower grips after straight: about 800mm Specifications: Overall dimensions: Electric cabinet: 600mm×600mm×1200mm Twisting tester: 350mm×280mm×1800mm Power supply: AC 380V 50/60Hz 5A
