GB / T 5023.1-2008 Load Off Core Tester
Product description: Load off core tester is used to load off core test of finished flexible cables, take a flexible cable specimen in appropriate length, mount one end of it on a rigid support, and hang a 0.5kg heavy hammer on the specimen 0.5m away from the bottom of the support point, when test current about 0.1A is charged in conductors, lift the heavy hammer to the support point and free fall, repeat five times, current interruption does not occur during the test Standard: • GB / T 5023.1-2008 Technical parameters: • Heavy hammer: 0.5kg • Test height: 0.8m • Test current: 0.1A • Test voltage: 12V Specifications: • Overall dimensions: 400mm × 450mm × 1180mm • Power supply: AC 220V 50 / 60Hz
