Automatic rebound angle tester

Performance Characteristics of Product ◆Executive standard: GB/T4074.3-2008/IEC60851-3; Inspection standard: JB/T4279.4-2008 ◆Used to measure the rebound resistance of enameled round wires with nominal conductor diameter of between 0.080mm and 1.600mm; ◆Application of SCM control allows for fast operation and strong anti-interference capacity; ◆Automatic stop after winding 5 circles; ◆Sensor is unnecessary to be adjusted for samples of different specifications; ◆Coils slowly loosen during springback, free from abrupt springback or bounce. ◆LED automatically records and displays test results; ◆Error between displayed value and indicating value on dial is no more than ±1°; ◆Simple operation, high sensitivity and excellent repeatability Major Technical Parameters Winding and rebound speed of sample 7±0.5 r /min Input power AC220V±10%  50Hz Consumed power ＜80W Overall dimensions L×W×H  560×314×360mm Weight 25kg ●Optional Model: HTJ-16A intelligent springback angle tester (Subject to standard NEMA and GB/T4074) ●Preparation of weight:                                Unit: N Load 0.25 0.50 1.0 2.0 4.0 8.0 12.0 15.0 Error ± 0.02 0.05 0.1 0.2 0.4 0.8 1.0 1.0 ●Preparation of test bar:                                 Unit: mm Diameter of test bar 5 7 10 12.5 19 25 37.5 50 Error ± 0.16 0.18 0.18 0.22 0.26 0.26 0.32 0.32
